Gen2+ image intensifier tube
| FOM | 2000+ |
| Sensitivity (μA/lm) | 1000+ |
| SNR | 28+ |
| Resolution(lp/mm) | 64-72 |
| Photo Cathode | S25R |
| Operating voltage (V) | 2.2-3.4 |
| Operating current (mA) | 25 |
| Luminance gain (cd/m²/lx) | 10000-20000 |
| Maximum output brightness (cd/m²) | 4~10 |
| EBI (μlx) | ≤0.25 |
| Working illumination range (lx) | 1×10–⁶~5×10⁴ |
| Uniformity of luminance(2856K) | 3:1 |
| Cathode effective diameter (mm) | ≥17.5 |
| Power supply | Auto-gate |
| Fluorescent powder | P43/P45 |
| Weight (g) | ≤80 |
| Power dissipation (mW) | 55-85 |
FOM1400+ image intensifier tube is a basic version product, which adopts a high-contrast optic fiber inverter and input enhancement technology with optional autogating. When the FOM reaches more than 1400, it can present excellent image quality in low light conditions. It is a cost-effective product.
FOM1600+ image intensifier tube adopts new MCP processing technology and new photocathode process. It is equipped with autogating and has the characteristics of high all-weather reliability. Compared with NVT4, its sensitivity is increased to more than 800, and the SNR is greater than 25.
FOM1800+ image intensifier tube uses the latest S25R photocathode manufacturing technology. The photocathode sensitivity is higher than 1000μA/lm@2856K, and it has high sensitivity in the near-infrared band. The spectral range is from 380nm to 1100nm, with higher spectral sensitivity in the near-infrared band, capable of imaging 1064nm lasers with halo reduced to less than 0.7mm.
