MH-CR540 Series Gen3 Night Vision Weapon Sight
Specification Gen3 | |
Model | MH-CR540 |
Magnification | 4x |
Field of view | 12º |
Lens system | 80mm F/1.4 |
Focus range | 10m to infinity |
Eye relief distance | 45mm |
Diopter setting,D | +3,-4 |
Overall dimensions | 280x95x82mm |
Weight | 1030g |
Power supply | 1CR123 battery,3V |
Estimated battery life | up to 60 hours |
Image Intensifier Tubes | |
Classification | OMNI II |
Photocathode type | 18mm S-25 |
Photocathode sensitivity | ≥550μA/lm |
Resolution | 57-64lp/mm |
Luminous gain | 19000-25000fl/fcd |
Signal-to-noise ratio | 20:1 or better |
FOM | ≥1150 |
Tube reliability standard | 10000 hours |
Keep time | 10 years |
Warranty | Oneyear |
Effective Distance | |
Detection range | 200-350m |
Recognition range | 180-220m |
5mW IR illuminator | up to 100m |
Environment Data | |
Operating temperature | -35℃to+50℃ |
Storage temperature | -35℃to+70℃ |
Humidity | up to 98% |
MH-CR Series Night Vision Weapon Sight use high performance Gen3 image intensifier tubes,which largely improves observation definition and extend your distance up to 450-700m.As long as the luminance is up to 0.001 Lux, you can engage in snipe all kinds of target in the wild at night.
Furthermore, this scope has the function of anti-glare, that is, it can be auto off when it aims at the strong light suddenly. And fits for city battle. It also matched with infrared equipment for compensating the brightness, which makes the military battle possible at different condition. Besides, it fits for international common standard picantiny rail, and it can be used for 7.62mm and 5.8mm snipe rifle respectively with mount rail systems.
FEATURES
1)superior for long range shooting
2)lightweight
3)internal-lit mil-dot illuminated red-on-green or yellow on-green reticle with adjustable brightness
4)top mounted internal front lens focus adjustment
5)precision internal wind-age/elevation Adjustment(1cl=10mm/m)
6)shockproof,can be used with heavy recoil(375 H&H,416 RIGBY,50 CAL)weapons standard weaver MIL-STP-1913 rail mount systtem 80% of value based on US made components and technology
7)automatic brightness control
8)protected against excess light exposure
9)easy to operste
10)photo/video equipment adaptable
11)rifle's zero adjustment is not required when change the type weapon
12)built-in hight power(75MW)IR illuminator with adjustable power level
13)water resistance
